The metal chip pressing machine will be pulverized iron chips, steel chips, copper chips, aluminum chips, high quality mineral powder, etc. directly cold pressed into cakes, in order to facilitate storage, transportation and furnace recycling.

Metal scrap briquette hydraulic press
Metal scrap briquette hydraulic press
Metal scrap briquette hydraulic press

About of Metal scrap briquette hydraulic press

  Metal block press can squeeze all kinds of metal scrap materials (steel shavings, scrap steel, scrap aluminum, scrap stainless steel and scrap automobile scrap, etc.) into cuboid, octagon, cylinder and other shapes of qualified charge. It can not only reduce the transportation and smelting cost, but also increase the furnace casting speed.


Product Advantage

  1. Hydraulic metal chip pressing machine is mainly used for various metalchips (iron chips, copper chips, aluminum chips, etc.), powder granular metal powder (iron powder, aluminum powder, copper powder, lead powder, etc.),
smelting additives, sponge iron, etc., without adding any adhesive to press into high-density cylindrical cake (weight 2-8 kg), cake density up to 5T/M3 or more (raw materials are different, The pressed cake density is not the same as the weight), the pressed cake can be directly used in the furnace, the cast iron grade can reach HT200-250, and the cost can be saved about 700 yuan per ton of casting.

  2. Adopt the latest hydraulic transmission technology, use high-quality wear-resistant oil seal, and the cylinder is processed and assembled by domestic high-tech technology, so as to ensure that continuous operation does not weaken the cylinder pressure, durable and smooth operation; Computer control, high degree of automation, low failure rate, easy maintenance, etc.




How is works

  The basic principle of the hydraulic metal press is to use the metalmaterial under the action of external force, can produce plastic deformation of the property, to the metal material with enough, can gather and produce deformation of the external force, so as to form a tight bundle. Therefore,plastic deformation can not be produced, or plastic deformation is very small metal, can not be directly packaged. Such as high carbon steel, tool steel, wire rope and cast iron, etc., can not be directly installed for packaging.


Product Specifications
*Note: Technical data are subject to change without prior notice.

Equipment model

 Pressure(ton)

Press bin sizemm

Bales sizecm

Press times

PowerkW

Y81-125

125

1200*800*500

30*30

100

15

Y81-135

135

1200*1000*600

30*30

110

18.5

Y81-160

160

1200*1000*600

35*35

110

18.5

Y81-180

180

1600*1200*800

40*40

130

22

Y81-200

200

1600*1200*800

50*50

140

22+15

Y81-250

250

2000*1750*1000

50*50

150

44

Y81-315

315

2500*2000*1200

50*50

170

60

Y81-400

400

3000*2500*1200

60*60

180

90



FAQ
